Cupped Head Weld Pin

From $124.20

Cupped Head (CH) Weld Pin is a mild steel fabricated part made up of a weld pin and a stacked on speed clip, or retaining washer.

The diameter of the head is 1-1/2″.

This product is generally applied with a capacitor discharge (CD) welder. The normal/standard material is galvanized steel (both head and plate).

Pins are also available “insulated” for welding through foil-faced materials to prevent arcing on the foil facia.

Material: Galvanized Steel, Stainless Steel available on special orders.

14ga available, please contact us.

*** ALL CUPPED HEAD PINS ARE SOLD 1,000 PIECES***

Cupped Head Weld Pins Spec Sheet

SKU: N/A Category:

Description

Cupped Head Weld Pin

The Cupped Head Weld Pin is a mild steel fabricated part made up of a weld pin and a stacked on speed clip, or retaining washer. The diameter of the head is 1-1/2″.

This product is generally applied with a capacitor discharge (CD) welder. The normal/standard material is galvanized steel (both head and plate).

PART NO. DCLENGTH
CH-12.1061-1/2"AS REQUIRED
CH-10.1351-1/2"AS REQUIRED
